3.37kw 8kg/H Natural Gas Waffle Cone Making Machine

3.37kw 8kg/H Natural Gas Waffle Cone Making Machine

  • 3.37kw 8kg/H Natural Gas Waffle Cone Making Machine
  • 3.37kw 8kg/H Natural Gas Waffle Cone Making Machine
3.37kw 8kg/H Natural Gas Waffle Cone Making Machine
Product Details:
Place of Origin: China
Brand Name: GongHeXiang
Certification: ISO
Model Number: SD80-37x2
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: RAW PACK
Delivery Time: 30-45DAYS
Payment Terms: T/T
Supply Ability: Sufficient supply
Contact Now
Detailed Product Description
Name: Sugar Cone Baking Machine Voltage: 380V
Input Power: 3.37kw LPG Consumption: 7-8kg/h
Net Weight: 4500kg Automatic: Full-automatic
Material: Stainless Steel Certification: ISO
PlC Control: Schneider Key Selling Points: Energy Saving
Usage: Waffle Biscuit Gelato Baking Line Whatsapp: 86 13346567737
High Light:

8kg/H Waffle Cone Making Machine

,

3.37kw Waffle Cone Making Machine

,

Natural Gas Sugar Cone Baking Machine


3.37kw 8kg/h Factory direct sales Natural Gas Suger Cone Baking Machine


Sugar Cone Baking Machine Introduction

SD80 series Sugar Cone Baking Machine is a kind of machine which controlled by PLC,with complete automatization ,high capacity and stable performance.It is very popular all over the world.
3.37kw 8kg/H Natural Gas Waffle Cone Making Machine 0

3.37kw 8kg/H Natural Gas Waffle Cone Making Machine 1


Sugar Cone Baking Machine Feature

♦ The machine is suitable for making flat mouth sugar cone length less than 135mm. Cone degree, weight, thickness and pattern spacing customized according to customer demand.



♦ The machine is driven by the 3 phases power and backing oven is heating with gas (natural gas or liquid gas), electric ignition, oven temperature electronic display. The producing ability is very high and it is all automatic from spraying the batter, baking, forming, falling off from molds, conveying products, stacking and counting.





3.37kw 8kg/H Natural Gas Waffle Cone Making Machine 2




Sugar Cone Baking Machine Working Principle
The Sugar Cone Baking Machine  is controlled by Schneider PLC, operated by the main motor, roller , solenoid valve and air fan, the baking plate of the machine is heated, after it shows about 180℃, the mixed batter will be pumped in a certain adjusted amount to the baking plate by the discharging pump, and automatically close the baking plate. The pastry is adjusted in a certain thickness, then the driving wheel drives baking plate into the oven from the upper and lower fire flame nozzle, after baking, the mixed batter has become a pastry, the machine hand accurately put the pastry into the roll mold to form finished product, after de-moulding, the finished product is sent out.

3.37kw 8kg/H Natural Gas Waffle Cone Making Machine 3

Sugar Cone Baking Machine Parameters


NameSD80-37x2
Voltage380vProduct size135mm
Total power3.37kwOutput/hour3500-4000pcs/h
LPG consumption7-8kg/hElectrical accessoriesSchneider
Machine dimensionL8XW2.1XH2MPLC controllerSchneider
Net weight4500kgControllerSchneider


Ice Cream Cone Making Machine Advantage

  1. Automated
  2. Advanced heating system
  3. Durable innoxious cone mould as per sanitation standard
  4. Temperature adjustable
  5. High-efficient heating element ensures ideal production ability.
  6. Different types of moulds according to your choice.
  7. A relay unit controls baking time.


FAQ

1. Ask:What is your guarantee of machine ?
Answer:usually our guarantee is 1 years.
2. Can you arrange your technicians to install the machine for us?
Answer:Yes,We will assign our engineers to go abroad for installing machines for our users.

3. Ask:how to install the machine ?

Answer:we can intrust the install the machine by vedio,email,picture.....if large project,we can arrange the worker help you to install it in your country .
