Home ProductsAutomatic Ice Cream Cone Machine

SD80-53A Maker Sugar Ice Cream Cone Make Production Line Crispy Cone Making Machine

SD80-53A Maker Sugar Ice Cream Cone Make Production Line Crispy Cone Making Machine

SD80-53A Maker Sugar Ice Cream Cone Make Production Line Crispy Cone Making Machine
SD80-53A Maker Sugar Ice Cream Cone Make Production Line Crispy Cone Making Machine
SD80-53A Maker Sugar Ice Cream Cone Make Production Line Crispy Cone Making Machine
Product Details:
Place of Origin: China
Brand Name: Gonghexiang
Certification: ISO
Model Number: SD80-53A
Payment & Shipping Terms:
Minimum Order Quantity: 1PS
Price: Negotiable
Packaging Details: RAW PACK
Delivery Time: 30-45DAYS
Payment Terms: T/T
Supply Ability: Sufficient supply
Contact Now
Detailed Product Description
VoltagE: 380V Total Power: 3.37 Kw
LPG Consumption: 8-10kg/h Capacity: 2800-3200pcs/h
Dimension: L8.5xW2.1xH2m Net Weight: 5300kg
Function: Multifunctional Raw Material: Wheat, Wheat Flour
Application Fields: Snack Food Factory, Beverage Factory Warranty: One Year
High Light:

automatic waffle cone maker

,

fully automatic wafer making machine

SD80-53A Maker Sugar Ice Cream ConeMake Production Line Crispy Cone Making Machine

SD80-53A Maker Sugar Ice Cream Cone Make Production Line Crispy Cone Making Machine 0

SD80-53A tunnel type automatic sugar cone making machine is a kind of PLC control, high degree of automation, high production efficiency, stable performance of the production machinery.

Voltage:380V
Total Power: 3.37kw
LPG consumption: 8-10kg/h
Capacity:2800-3200pcs/h
Dimension:L8.5xW2.1xH2m
Net weight:5300kg
Electrical accessories:French brand: Schneider
Controller:French brand : Schneider

Working principle:
Feeding the mixed flour paste by feeding pump to the baking plate and automatically close the baking plate, forming as the thickness of the dough,then put into the oven to bake.After baking ,the paste has forming.Using the manipulator to put it in the mould of rolling to make the finished products.after demould conveyor the products.

Standard equipment:
1,conveyor
SD80-53A Maker Sugar Ice Cream Cone Make Production Line Crispy Cone Making Machine 1
Voltage:220V
Power:0.75kw
Dimension: 5mx0.6mx0.7m

It is used to deliver the finished products to the assembly shop in a neat line.

2,optional equipment : automatic counting machine
SD80-53A Maker Sugar Ice Cream Cone Make Production Line Crispy Cone Making Machine 2
Power: 0.75kw
Dimension: 2mx0.9mx0.7m

It is used to automatically stack the molded products of the paper sleeve into a string, and wait for the box according to the set number. The set value is 1-50/string.


2. Advantage of Sugar Cone Baking Machine
1. Easy Operation
2. Advanced heating system
3. Durable innoxious cone mould as per sanitation standard
4. Temperature adjustable
5. High-efficient heating element ensures ideal production ability.
6. Different types of moulds according to your choice.
7. A relay unit controls baking time.



ModelInput powerMachine dimensionweightLPG consumptionBaking plate quantity/machineProduct size(mm)Output/hour
SD80-37x23.37kwL8XW2.1XH2M4500kg7-8kg/h37135mm3500-4000pcs/h
SD80-37A3.37kwL6.6xW2.1xH2m3800kg5-6kg/h37165mm1800-2000pcs/h
SD80-45x23.37kwL8.6XW2.1XH2M5000kg10-12kg/h45135mm4500-5000pcs/h
SD80-45A3.37kwL8xW2.1xH2m4800kg7-8kg/h45165mm2200-2500pcs/h
SD80-53x23.37kwL10.3xW2.1xH1.8m5800kg10-12kg/h53135mm5000-6000pcs/h
SD80-53A3.37kwL8.5xW2.1xH2m5300kg8-10kg/h53165mm2800-3200pcs/h
SD80-61x24.07kwL12.2xW2.1xH2M7000kg16-18kg/h61135mm6000-7000pcs/h
SD80-61A4.37kwL9.8xW2.1xH2m6000kg10-12kg/h61165mm3400-3800pcs/h
SD80-69x24.37kwL13.5xW2.1xH2M7800kg18-20kg/h69135mm7000-7500pcs/h
SD80-69A4.37kwL11xW2.1xH2m6800kg14-16kg/h69165mm3800-4200pcs/h
Final Products

SD80-53A Maker Sugar Ice Cream Cone Make Production Line Crispy Cone Making Machine 3SD80-53A Maker Sugar Ice Cream Cone Make Production Line Crispy Cone Making Machine 4

FAQ

1. Ask:What is your guarantee of machine ?
Answer:usually our guarantee is 1 years.
2. Can you arrange your technicians to install the machine for us?
Answer:Yes,We will assign our engineers to go abroad for installing machines for our users.
3. Ask:About the machine voltage or power of machine ?
Answer:Usually in our country is 220v,50hz, single phase,or 380v,50hz,3 phase.if you have the special requirement,pls tell us, we will vetify the voltage according to your requirement.
4. Ask:how to install the machine ?
Answer:we can intrust the install the machine by vedio,email,picture.....if large project,we can arrange the worker help you to install it in your country .

Our Services
♥. Pre-sale-service:Design and manufacture machines for you as your special requirement, provide you with project, process design and pruchase program.

♥. On-sale-service: Accompany with you to look around our factory, explain the manufacture process of our machines and check the working performance of our machine.

♥. After-sale-service: Engineers are available to install debugging equipments of the whole production line, besides, commissioning and training operators on site.

After Sale Service

1. Warranty policy one year from shipment
2. We will send you the replacement after received the broken part
3. Evaluate the customs rish and choose safest shipping company before shipping.
4. Follow status up time by time until the goods arrived.

Packaging & Shipping

1. We always use standard export wooden packing,carton box.
2. You can choose express, by air,by train or by sea.Always we will give our best recommend based on our experience.
3. We cooperate with China best shipping company to get best price and fast delivery.
4. You will get full feedback when your machine is on the way.
