Guang Zhou Jian Xiang Machinery Co. LTD
 |
| Place of Origin: | China |
| Brand Name: | GongHeXiang |
| Certification: | ISO |
| Model Number: | SD80-45x2 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | RAW PACK |
| Delivery Time: | 30-45DAYS |
| Payment Terms: | T/T |
| Supply Ability: | Sufficient supply |
| Name: | Sugar Cone Machine | Voltage: | 380V |
|---|---|---|---|
| Power: | Electric | LPG Consumption: | 8-10kg/h |
| Capacity: | 4000-5000pcs/h | Type: | Ice Cream Maker Machine |
| Application: | Ice Cream Cone | Raw Material: | Wheat, Wheat Flour |
| Automatic: | Full-automatic | Local Service Location: | None |
| Material: | Stain Steel | Whatsapp: | 86 13346567737 |
| High Light: | 380V Ice Cream Cone Making Machine,10kg/h Ice Cream Cone Making Machine,PLC ice cream cone manufacturing machine |
||
304 Stain Steel 380V Industrial Ice Cream Maker Machine
The whole machine is controlled by schneider PLC, through the main motor startup, roll machine, fan starts, gas start, and the igniter is automatically ignited to heat the baking plate of the machine.Until the temperature shows about 180 degrees,The mixed dough is sent to the bottom plate of the baking plate by the dosing pump, and the panel of the baking plate is automatically closed.The dough is shaped according to the set thickness of the dough, and then the baking plate is driven by the active wheel. Transfer to an oven consisting of upper and lower fire mouths, etc.After baking, the pasta has become a pastry, and the dough is accurately put into a rolling mold by a manipulator it into a finished product, and the finished product is sent out after demolding
Sugar Cone Machine Introduction
Sugar Cone Machine Advantage
Sugar Cone Machine Parameters
| Name | SD80-45x2 Sugar Cone Machine | ||
| Voltage | 380v | Product size | 120mm |
| Total power | 3.37kw | Output/hour | 4000-5000pcs/h |
| LPG consumption | 8-10kg/h | Electrical accessories | Schneider |
| Machine dimension | L8.7xW2.1xH2 M | PLC controller | Schneider |
| Net weight | 50000kg | Controller | Schneider |
After Sale Service
1. Warranty policy one year from shipment.
2. We will send you the replacement after received the broken part
3. Evaluate the customs rish and choose safest shipping company before shipping.
4. Follow status up time by time until the goods arrived.
Exhibition
Contact Person: Katrina
Tel: +86 15913188664
