Multifunctional Ice Cream Cone Baking Machine For Sugar Rolled Cone , Egg Roll

Multifunctional Ice Cream Cone Baking Machine For Sugar Rolled Cone , Egg Roll

  • Multifunctional Ice Cream Cone Baking Machine For Sugar Rolled Cone , Egg Roll
Multifunctional Ice Cream Cone Baking Machine For Sugar Rolled Cone , Egg Roll
Product Details:
Place of Origin: China
Brand Name: GongHeXiang
Certification: ISO
Model Number: SD80-45x2
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: RAW PACK
Delivery Time: 30-45DAYS
Payment Terms: T/T
Supply Ability: Sufficient supply
Contact Now
Detailed Product Description
Type: Ice Cream Cone Baking Machine Voltage: 380V
Input Power: 3.37kw LPG Consumption: 8-10kg/h
Feature: Multifunctional Net Weight: 5000Kg
Application Fields: Sugar Rolled Cone , Egg Roll Automatic: Full-automatic
High Light:

sugar cone baking machine


auto cone machine

Multifunctional Ice Cream Cone Baking Machine For Sugar Rolled Cone , Egg Roll​
Ice Cream Cone Baking Machine description
The machine is made of the thick the steel plate plates, and the upper and lower is made of thick iron template (without the weaknesses of the aluminum egg roll machine), import heating equipment, good heat resistance enhances the durability.internal heating tube layout is reasonable, the cone is heated evenly with bright color. Equipped with temperature control device, can adjust the temperature range from 50 to 360 ℃. In the working process, temperature iscontrolled accurately, guaranteeing the superior quality of the products. good aafety performance and high temperature resistant can guarantee the continuous working with the high efficiency, is an ideal equipment to make high quality egg rolls in the present domestic market.
Ice Cream Cone Baking Machine Working Principle
The whole machine is controlled by Schneider PLC, operated by the main motor, roller , solenoid valve and air fan, the baking plate of the machine is heated, after it shows about 180℃, the mixed batter will be pumped in a certain adjusted amount to the baking plate by the discharging pump, and automatically close the baking plate. The pastry is adjusted in a certain thickness, then the driving wheel drives baking plate into the oven from the upper and lower fire flame nozzle, after baking, the mixed batter has become a pastry, the machine hand accurately put the pastry into the roll mold to form finished product, after de-moulding, the finished product is sent out.

Ice Cream Cone Baking Machine Parameters

NameSD80-45x2 Ice Cream Cone Baking Machine
Voltage380vProduct size120mm
Total power3.37kwOutput/hour4000-5000pcs/h
LPG consumption8-10kg/hElectrical accessoriesSchneider
Machine dimensionL8.7xW2.1xH2 MPLC controllerSchneider
Net weight50000kgControllerSchneider

1. Ask:What is your guarantee of machine ?
Answer:usually our guarantee is 1 years.
2. Can you arrange your technicians to install the machine for us?
Answer:Yes,We will assign our engineers to go abroad for installing machines for our users.
3. Ask:About the machine voltage or power of machine ?
Answer:Usually in our country is 220v,50hz, single phase,or 380v,50hz,3 phase.if you have the special requirement,pls tell us, we will vetify the voltage according to your requirement.
Company Profile
      Guangzhou Jianxiang Machinery Co., Ltd. has more than 20 years of experience in the production of mechanical products. Now the company has strong technical force, advanced equipment and normative management after many years of struggle and technology accumulation. Our business partner Guangzhou GongHeXiang Machinery Co., Ltd, is the most famous automatic sugar cone baking machine manufacturer in China. The sugar cone baking machine and batter mixer we produce for GongHeXiang had been sold to over 20 provinces in China and exported to many oversea countries like Russia, Kyrgyzstan, Uzbekistan, Turkey, Argentina, Vietnam, Syria, French Polynesia, Egypt, Peru, India etc.
In order to meet market needs and customer’s demand, besides the most regular TT25 sugar cone baking machine, we developed new model TT25-40, TT25-36 and TT25-30 of the TT25 series. TT26 series are electric baking machine which include model TT26-45, TT26-40, TT26-36 and TT26-30. SD80 series are the most advanced caterpillar track type baking machine, which include model SD80-37x2 and model SD80-53x2.
Different machine can meet your different requirement for sugar cone size and your demand for production capacity. After so many years of development, our company had truly become the most professional sugar cone baking machine manufacturer in China.
Customer first, quality first and user-oriented is key to our service. Our company always provide customer with high quality product and good service and we will constantly strive for excellence. We believe our reasonable offer and thoughtful after-sales service can allow users achieve a real “buy peace of mind was at ease with”. We warmly welcome both new and current customer to call for further inquiry or to come and discuss cooperation.
