Automatic PLC 3500pcs/h Ice Cream Cone Baking Machine

Automatic PLC 3500pcs/h Ice Cream Cone Baking Machine

  • Automatic PLC 3500pcs/h Ice Cream Cone Baking Machine
  • Automatic PLC 3500pcs/h Ice Cream Cone Baking Machine
Automatic PLC 3500pcs/h Ice Cream Cone Baking Machine
Product Details:
Place of Origin: China
Brand Name: Gonghexiang
Certification: ISO
Model Number: SD80-L37X2
Payment & Shipping Terms:
Minimum Order Quantity: 1PS
Price: Negotiable
Packaging Details: RAW PACK
Delivery Time: 30-45DAYS
Payment Terms: T/T
Supply Ability: Sufficient supply
Contact Now
Detailed Product Description
Name: Ice Cream Cone Plant Capacity: 3500-4000pcs/h
VoltagE: 380V Total Power: 3.37 Kw
LPG Consumption: 7-8kg/h Feature: Energy Saving
Warranty: One Year Material: Stainless Steel
Certification: ISO9001 Application: Ice Cream,Food
Production Scope: Product Line Process: Thermal Processing
High Light:

3500pcs/h Ice Cream Cone Baking Machine

,

PLC Ice Cream Cone Baking Machine

,

SS Sugar Cone Making Machine

Two Color High Capacity And Durable Automatic Ice Cream Cone Machine



Working Principle:



Feeding the mixed flour paste by feeding pump to the baking plate and automatically close the baking plate, forming as the thickness of the dough, then put into the oven to bake. after baking, the paste has forming. using the manipulator to put it in the mould of rolling to make the finished products. after demould conveyor the products.





Specifications:



Voltage: 380v Product size: length less than 135mm
Total power: 3.37kw Output/hour: 3500-4000pcs/h
LPG consumption: 7-8kg/h Electrical accessories Schneider
Machine dimension: L8XW2.1XH2M PLC controller: Schneider
Net weight: 4500kg Controller: Schneider





Automatic PLC 3500pcs/h Ice Cream Cone Baking Machine 0



Automatic PLC 3500pcs/h Ice Cream Cone Baking Machine 1





Process:



1. The stirred dough is delivered to the baking pans by the slurry pump.

2. The upper and lower plates of the baking plate are automatically closed, and the cakes are baked according to the preset thickness of the cakes.

3. When the baking plate turned to the position of the manipulator(it has been baked already), and the manipulator absorbs baked cake sends them to the forming mold.

4. The forming mold rolls the cake into a cone shape, and then sends it to the conveyor belt for the arrangement.



Automatic PLC 3500pcs/h Ice Cream Cone Baking Machine 2



FAQ



1. Ask:What is your guarantee of machine ?

Answer:usually our guarantee is 1 years.

2. Can you arrange your technicians to install the machine for us?

Answer:Yes,We will assign our engineers to go abroad for installing machines for our users.

5.Ask: Are you factory or trading company?

Answer: We are a factory in this field nearly 20 years.

6.Ask:Are there any accessories for the purchase of the machine?

Answer:Yes,We will give away random accessories and some installation tools.







After Sale Service



♥. On-sale-service: Accompany with you to look around our factory, explain the manufacture process of our machines and check the working performance of our machine.

♥. After-sale-service: Engineers are available to install debugging equipment of the whole production line, besides, commissioning and training operators on site.



Packaging & Shipping



1. We always use standard export wooden packing,carton box.

2. You can choose express, by air,by train or by sea.Always we will give our best recommend based on our experience.

Automatic PLC 3500pcs/h Ice Cream Cone Baking Machine 3



Welcome to contact us with your cone pictures,design,size and capacity then we can talk more and suggest you the suitable ice cream cone machines.
