Multifunctional Wafer Cone Production Line 3800pcs/h Ice Cream Cone Baking Machine

Multifunctional Wafer Cone Production Line 3800pcs/h Ice Cream Cone Baking Machine

  • Multifunctional Wafer Cone Production Line 3800pcs/h Ice Cream Cone  Baking Machine
  • Multifunctional Wafer Cone Production Line 3800pcs/h Ice Cream Cone  Baking Machine
Multifunctional Wafer Cone Production Line 3800pcs/h Ice Cream Cone  Baking Machine
Product Details:
Place of Origin: China
Brand Name: Gonghexiang
Certification: ISO
Model Number: SD80-61A
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: RAW PACK
Delivery Time: 30-45DAYS
Payment Terms: T/T
Supply Ability: Sufficient supply
Contact Now
Detailed Product Description
Name: Wafer Cone Production Line LPG Consumption: 10-12kg/h
Capacity: 3400-3800pcs/h Net Weight: 6000kg
Function: Multifunctional Warranty: One Year
Process: Thermal Processing Material: Stainless Steel
Raw Material: Wheat, Wheat Flour Core Components: PLC, Engine
High Light:

Multifunctional Wafer Cone Production Line

,

3800pcs/h Wafer Cone Production Line

,

PLC Ice Cream Waffle Cone Machine

Multifunctional Wafer Cone Production Line / Ice Cream Cone Baking machine



Multifunctional Wafer Cone Production Line 3800pcs/h Ice Cream Cone  Baking Machine 0





Quick Detail



The stirred dough is sent to the baking plate bottom plate by the blanking pump, and the panel of the baking plate is automatically closed, and the dough cake is shaped according to the thickness of the set cake, and then the rotating plate is turned into a baking plate. It is baked in an oven consisting of upper and lower fire nozzles. After baking, the noodle paste has become a dough cake. The robot cake accurately feeds the dough cake into the roll mold and rolls it into a finished product. The finished product is delivered.





Wafer Cone Production Line Features



1. Our Ice Cream Cone Product Line can also be custom-made to suit your product of different specifications.
2. One bIce Cream Cone Product Line can produce different products like waffle ,egg roll,sugar cone etc.by choosing different moulds.
3. One person operation,convenient and practical. High quality electrical components,temperature control thermostat using Promise.





Wafer Cone Production Line Parameters



Model Input power Machine dimension weight LPG consumption Baking plate quantity/machine Product size(mm) Output/hour
SD80-61A 4.37kw L9.8xW2.1xH2m 6000kg 10-12kg/h 61 165mm 3400-3800pcs/h





Standard equipment:

1,conveyor

Multifunctional Wafer Cone Production Line 3800pcs/h Ice Cream Cone  Baking Machine 1

Voltage:220V

Power:0.75kw

Dimension: 5mx0.6mx0.7m



It is used to deliver the finished products to the assembly shop in a neat line.



2,optional equipment : automatic counting machine

Multifunctional Wafer Cone Production Line 3800pcs/h Ice Cream Cone  Baking Machine 2

Power: 0.75kw

Dimension: 2mx0.9mx0.7m



It is used to automatically stack the molded products of the paper sleeve into a string, and wait for the box according to the set number. The set value is 1-50/string.



Final Products

Multifunctional Wafer Cone Production Line 3800pcs/h Ice Cream Cone  Baking Machine 3Multifunctional Wafer Cone Production Line 3800pcs/h Ice Cream Cone  Baking Machine 4



FAQ



Q: Can you arrange your technicians to install the machine for us?

A: Yes,We will assign our engineers to go abroad for installing machines for our users.

Q: How about delivery?

A:We can help you transport, or we can provide you with the size of the machine, you can consult the forwarding company yourself.

Q:What's the MOQ?

A:The MOQ(minimum order quantity) is one set.

Q:How could we operate such equipment after getting it in our country.

A:We will teach our customer the operation process,and provide them the operating video.



Company Profile



      Guangzhou Jianxiang Machinery Co., Ltd. has more than 20 years of experience in the production of mechanical products. Now the company has strong technical force, advanced equipment and normative management after many years of struggle and technology accumulation. Our business partner Guangzhou GongHeXiang Machinery Co., Ltd, is the most famous automatic sugar cone baking machine manufacturer in China. The sugar cone baking machine and batter mixer we produce for GongHeXiang had been sold to over 20 provinces in China and exported to many oversea countries like Russia, Kyrgyzstan, Uzbekistan, Turkey, Argentina, Vietnam, Syria, French Polynesia, Egypt, Peru, India etc.



In order to meet market needs and customer’s demand, besides the most regular TT25 sugar cone baking machine, we developed new model TT25-40, TT25-36 and TT25-30 of the TT25 series. TT26 series are electric baking machine which include model TT26-45, TT26-40, TT26-36 and TT26-30. SD80 series are the most advanced caterpillar track type baking machine, which include model SD80-37x2 and model SD80-53x2.
