Home ProductsIce Cream Cone Production Line

3800pcs/H Wafer Ice Cream Cone Production Line Multifunctional

3800pcs/H Wafer Ice Cream Cone Production Line Multifunctional

3800pcs/H Wafer Ice Cream Cone Production Line Multifunctional
3800pcs/H Wafer Ice Cream Cone Production Line Multifunctional
3800pcs/H Wafer Ice Cream Cone Production Line Multifunctional
Product Details:
Place of Origin: China
Brand Name: Gonghexiang
Certification: ISO
Model Number: SD80-61A
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: RAW PACK
Delivery Time: 30-45DAYS
Payment Terms: T/T
Supply Ability: Sufficient supply
Contact Now
Detailed Product Description
Features: Factory Price Name: Wafer Cone Production Line
LPG Consumption: 10-12kg/h Capacity: 3400-3800pcs/h
Net Weight: 6000kg Function: Multifunctional
Certification: CE Certificate Warranty: One Year
Type: Processing Line Core Components: PLC, Engine
High Light:

Wafer Ice Cream Cone Production Line

,

3800pcs/H Ice Cream Cone Production Line

,

Multifunctional Ice Cream Cone Production Line

Wafer Ice Cream Cone Production Line Full Automatic Multifunctional 3800pcs/H Capacity

High Capacity Multifunctional Wafer Cone Production Line



3800pcs/H Wafer Ice Cream Cone Production Line Multifunctional 0



Wafer Cone Production Line Working principle:



The stirred dough is sent to the baking plate bottom plate by the blanking pump, and the panel of the baking plate is automatically closed, and the dough cake is shaped according to the thickness of the set cake, and then the rotating plate is turned into a baking plate. It is baked in an oven consisting of upper and lower fire nozzles. After baking, the noodle paste has become a dough cake. The robot cake accurately feeds the dough cake into the roll mold and rolls it into a finished product. The finished product is delivered.



3800pcs/H Wafer Ice Cream Cone Production Line Multifunctional 1





Features of ice cream cone production line:



1. Automatic wafer baking oven equipped with Touch-screen and programmed by Siemens. PLC Software,this unit is of natural gas to generate the heat energy to make ice cream cone

2. The equipment is easy to operate which with automatic temperature control,lighting to finish the baking process.

3. From filling flour paste to get a ice cream cone just need 2mins,one time molding.High efficiency.





Wafer Cone Production Line Parameters



Model Input power Machine dimension weight LPG consumption Baking plate quantity/machine Product size(mm) Output/hour
SD80-61A 4.37kw L9.8xW2.1xH2m 6000kg 10-12kg/h 61 165mm 3400-3800pcs/h



3800pcs/H Wafer Ice Cream Cone Production Line Multifunctional 2





1. Ask:What is your guarantee of machine ?

Answer:usually our guarantee is 1 years.



2. How about your after-sales service?
Our engineer can go outside to install and train your workers to operate the full machine line.



3. Ask:About the machine voltage or power of machine ?

Answer:Usually in our country is 220v,50hz, single phase,or 380v,50hz,3 phase.if you have the special requirement,pls tell us, we will vetify the voltage according to your requirement.



4. Ask:how to install the machine ?

Answer:we can intrust the install the machine by video,email,picture.....if large project,we can arrange the worker help you to install it in your country .



5.Ask: Are you factory or trading company?

Answer: We are a factory in this field nearly 20 years.
